Maxx Side Dump Bucket for Skid Steer with Hydraulic Cylinder

The Maxx Side Dump Buckets are versatile attachments designed to excel in a variety of demanding tasks, including tunnel construction, levee building, trench filling, and asphalt roadway demolition. These buckets handle materials such as sand, gravel, loose dirt, and rock, providing efficient solutions for various applications. Their innovative side-dumping design is especially useful for maneuvering in crowded work sites and tight spaces, making them invaluable for complex environments. Additionally, the buckets can also dump forward, functioning like a conventional bucket when needed.

Whether you're navigating tricky areas or working in challenging conditions, the Maxx Side Dump Buckets offer the flexibility and performance you need for optimal efficiency.

Key Features

• Versatile Design: Ideal for a range of applications like tunnel construction, trench filling, and asphalt demolition.
• Side Dumping: Allows for dumping on either the left or right side, perfect for crowded job sites or confined spaces.
• Forward Dumping: Functions like a conventional bucket when side dumping is not required.
• Heavy-Duty Hydraulic Cylinder: Equipped with a single cylinder featuring a load-holding valve for enhanced safety and durability.
• Universal Mounting: Includes a universal skid steer mount, making it compatible with skid steers, compact track loaders, and compact wheel loaders.
• Custom Options Available: Optional rock rack and V-type cutting edge for heavy-duty rock loading.

Detailed Specifications

• Capacity Options:
  • 0.60 Cubic Yard Capacity:
    • Width: 72"
    • Cylinder Bore: 3.5"
    • Rod: 2"
    • Stroke: 18"
    • Operating Pressure: 3000 PSI
    • Max Flow Rate: 15-20 GPM
    • Moldboard Thickness: 0.25"
    • Weight: 1250 lbs
  • 0.75 Cubic Yard Capacity:
    • Width: 80"
    • Cylinder Bore: 3"
    • Rod: 1.75"
    • Stroke: 18"
    • Operating Pressure: 3000 PSI
    • Max Flow Rate: 15-20 GPM
    • Moldboard Thickness: 0.25"
    • Weight: 1330 lbs
  • 1.12 Cubic Yard Capacity:
    • Width: 82"
    • Cylinder Bore: 3.5"
    • Rod: 2"
    • Stroke: 18"
    • Operating Pressure: 3000 PSI
    • Max Flow Rate: 15-20 GPM
    • Moldboard Thickness: 0.25"
    • Weight: 1490 lbs

What's Included:

• Universal skid steer mount
• Hoses and flat-faced couplers
• Owner's Manual

Options Available:

• Rock Rack: For heavy-duty rock handling.
• V-Type Cutting Edge: Ideal for tough rock loading tasks.

How To Get an Options Quote:

Option 1:
Click on "Contact Us" to ensure you're getting the best upgrades and options available. Our team will assist you in choosing the ideal setup for your needs.

Option 2: (Quickest Response)

1. Add the item to your cart.
2. Click the Chat button in the bottom-right corner.
3. Tell us which upgrades or options you're interested in, along with any other relevant information.
4. Relax while our expert team processes your request to get you exactly what you need!
