Cold Planer
The value and popularity of Bradco's skid steer cold planer attachments are becoming increasingly more evident because of the variety of jobs they can assist with. In addition to small milling jobs in which large milling machines can't efficiently be used, cold planers are an effective tool for asphalt and concrete pothole and frost heave repair, curb cutting, pavement texturing for improved skid resistance, and the removal of traffic lane stripes and roadway around manholes. This product is also available CE certified.
- Planetary drive delivers high torque
- High rear spoil clearance to prevent re-circulation of material
- Protective shields for hydraulic and electrical components
- Efficient piston drive motor
- Optional water tank available with adjustable mounting brackets to fit most skid steer loaders
SPECIFICATIONS
| MODEL | HP400 | HP450 | HP600 |
| REQ FLOW | HIGH FLOW | HIGH FLOW | HIGH FLOW |
| REQ RANGE | 22-40 GPM | 22-40 GPM | 22-40 GPM |
| WIDTH | 65" | 65" | 65" |
| HEIGHT | 35" | 35" | 35" |
| LENGTH | 50" | 50" | 50" |
| WORKING WIDTH | 16" | 18" | 24" |
| WORKING DEPTH | 0-5" | 0-5" | 0-5" |
| TILT | 8 | 8 | 8 |
| DRUM | 22" | 22" | 22" |
| PICKS | 43 | 45 | 57 |
| CENTER TO RIGHT | 3-22" | 3-22" | 3-22" |
| PRESSURE | 2500-3000 | 2500-3000 | 2500-3000 |
| MODEL | HP750 | HP1000 |
| REQ FLOW | HIGH FLOW | HIGH FLOW |
| REQ RANGE | 22-40 GPM | 22-40 GPM |
| WIDTH | 65" | 65" |
| HEIGHT | 35" | 35" |
| LENGTH | 50" | 50" |
| WORKING WIDTH | 30" | 40" |
| WORKING DEPTH | 0-5" | 0-5" |
| TILT | 8 | 8 |
| DRUM | 22" | 22" |
| PICKS | 69 | 89 |
| CENTER TO RIGHT | 3-22" | 3-22" |
| PRESSURE | 2500-3000 | 2500-3000 |
- Fully adjustable with electrohydraulic controls
- Manual depth and tilt option available on standard flow Cold Planer ONLY
- Convenient for milling frost heaves, expansion joints, railroad approaches, etc.
- Water nozzle kit standard with integral water nozzle ports
- Optional in-cab control harness for most skid-steer loader models
- Pick maintenance tool included and stowed with the Cold Planer
- Convenient ergonomic electrohydraulic control joystick for depth, tilt and side shift standard
- Independent self-leveling depth adjustment plates which allow for precise lapping cuts and taper cuts
- Replaceable steel bushings at pivot locations
- Efficient piston drive motor
- Solid hardened steel wheels with greasable manifold pins and secluded greased zerks
- Exclusive angled spoil guard wheel design prevents wheels from riding up and over millings, this feature provides more force to the cutting action by significantly reducing rolling resistance and allow for maintained control over depth of cut
SHIPPING
VARIES ON MODEL
OPTIONS
CONTROLS 4 FUNCTION
- 114874 - BOBCAT, DITCH WITCH, GEHL, MUSTANG, JCB, TAKEUCHI, VOLVO
- 116745 - CNH, KUBOTA SVL-2
- 114969 - JOHN DEERE
- 115403 - BRADCO CONTROL HANDLE
- 120262 - CAT D SERIES
CONTROLS 3 FUNCTION
- 19644 - BOBCAT, CNH, GEHL, JCB, MUSTANG, VOLVO, WACKER
- 108618 - JOHN DEERE
- 19644 - KUBOTA
- 118650 - BRADCO CONTROL HANDLE ASSEMBLY
- 120337 - TAKEUCHI
- 122128 - CAT D SERIES
OTHER OPTIONS
- 30 GAL WATER TANK W/O ELECTRIC CONTROL BOX
- 30 GAL WATER TANK W/ ELECTRIC CONTROL BOX
- 2.5" STANDARD FLOW SLOT CUTTER
- 2.5" HIGH FLOW SLOT CUTTER
- 4" HIGH FLOW SLOT CUTTER
- 6" HIGH FLOW SLOT CUTTER
